Three insulation resistance (IR) test modes
Insulation (InS), Polarisation Index (PI), and variable timed test (t) modes are available in any IR test range
CAT III 600 V rated with additional safety features
Including high voltage warning indicator, external voltage display after IR test, automatic discharge of reactive loads, and test leads
Guard terminal for accurate results
Helps obtain accurate results when performing tests on items that have significant surface leakage
Perform DC insulation tests
Five test ranges at 250 V, 500 V, 1000 V, 2500 V, and 5000 V covering a measuring range of 100 kΩ to 1000 GΩ
